Diesel Trackless Train
Model No.: GS-DTT-42
The power source of trackless train is mainly divided into two kinds, fuel driven and battery driven. The main carriages are divided into two types: full enclosed compartments and open type carriages. As a special transportation tool, tourist train not only plays the role of transportation, but also makes visitors enjoy the scenery along the way. Some tourist trains can also provide leisure service.
- Share
- OVERVIEW
- PARAMETER
- RELATED PRODUCTS
- LEAVE A MESSAGE
- PRODUCT INTRODUCTION
-
The power source of trackless train is mainly divided into two kinds, fuel driven and battery driven. The main carriages are divided into two types: full enclosed compartments and open type carriages.
As a special transportation tool, tourist train not only plays the role of transportation, but also makes visitors enjoy the scenery along the way. Some tourist trains can also provide leisure service.
Diesel Power Trackless Train Technical Data Performance Capacity 40+2 Top speed 30km/h Max. Climbing ability 25%,afford long time climbing Min.Brake diatance 4m,under full load condition Min.Turning Radius 7m Dimensions Overall dimension(m) 14.6*1.98*2.5 Locomotive and Carriage(mm) Locomotive: 4200*1700*2400 Carriage:4000*1980*2500 Wheelbase(mm) 2600 Tyre &Tread(mm) 14inch tyre ,tread 600-14 Min ground Clearance(mm) 145 Engine Mode&brand 4B2-52M22 Quan Chai diesel engine Rated speed 2400r/min Intake model naturally aspirated Brand QUAN CHAI Emission standard Euro III Gearbox manual control 5+1 Brake system Brake system type Air-assisted oil(Hydraulic drum air brake) Emergency brakes Brake automatically encounter the connectionbreak situation Steering Steering control Four-wheel steering Drag system Drag rod Swing tow bar from China Other configuration Materials Body and seat:Fiberglass Chassis structure:Advanced steel pipe Rust prevention Pickling + phosphating + rust paint Painting automotive grade paint, computer paint, professional spray Floor of carriages Stainless steel non-slip flooring Lights Front lights, combination taillights, warning lights, driving lights, brake lights, turn lights Media players MP5 player, locomotive and carriages with the 7-inch display and 19-inch LED screen Fan Movable mini fan Camera system Brand-SAFUYWE,China 7 inch screen * 1, camera * 1, control center * 1. Each carriage has a built-in camera Seat belt 3C certified seat belt Plastic safety chains Chain*10pcs each carriage Station reporter professional bus station reporting system with GPS Smoke Blow smoke Seat in locomotive The driver’s seat can be adjusted forwards and backwards -
- PRODUCT SUPERIORITY
-
1. Tourist Train is a special way of transportation in scenic area,at the same time, itself is an important tourist attraction.
-
2. Tourist Train can integrate multiple scenic spots, especially for large scenic spots, scenic small train is an effective tool to improve traffic accessibility of scenic spots.
-
3.To make Tourism landscape along the way to be rich and varied, various scenes, visual gluttonous dinner for tourists.
-
4.Sightseeing stations should be built along the Tourist Trains. Besides the necessary tourist facilities, scenic sightseeing stations should also have colorful tourist activities and projects.
-
5.Tourist Train can be effectively coordinated with other means of transportation, effectively organize the traffic system of scenic spots, and achieve seamless docking between scenic spots.
